Resources
Equipment:
1. N5222A Keysight PNA Microwave Network Analyzer
This Network Analyzer is able to measure up to 26.5 GHz. It has a dynamic range of 127dB and output power of 13dBm. In addition, it has 4 built-in ports.
2. N4691D Keysight Electronic Calibration Module (ECal)
The Keysight N4691D microwave electronic calibration (ECal) module makes calibration of Keysight vector network analyzers fast, easy and accurate. This high accuracy 2-port ECal module supports 3.5 mm connectors. It is able to cover frequencies from 300 kHz to 26.5 GHz or DC to 26.5 GHz.
3. N5172B Keysight EXG X-Series RF Vector Signal Generator
This RF Vector Signal Generator covers frequencies from 9 kHz to 6 GHz. It has a phase noise of -122 dBc/Hz at 1 GHz, and -144 dBm to +26 dBm output power at 1 GHz. The harmonics of this vector signal generator at 1 GHz are less than -35 dBc. The frequency switching of this vector signal generator is less than 800 us. It also has an IQ modulation BW of 120 MHz to 200 MHz. In addition, this device provides sweep modes of list and step.
4. MSOS404A Keysight High-Definition Oscilloscope
This oscilloscope has 4 GHz bandwidth, and 4 channels. The memory depth per channel for this oscilloscope is 200 Mpts. A 10 bit ADC has been employed inside this oscilloscope.
5. DSOX1102A Keysight Oscilloscope
This two-channel oscilloscope has 70 MHz bandwidth. The maximum memory bandwidth of it is 1Mpts and the maximum sampling rate of it is 2 GS/s. An 8 bit ADC has been employed inside this oscilloscope.
6. E3648A Keysight Power Supply
This power supply is dual output. One of the outputs is 8 V / 5 A, and the other output is 20 V / 2.5 A.
7. 33611A Keysight Waveform Generator
This 1-channel waveform generator pulses up to 80 MHz with less than 1 ps jitter for more precise timing. It also has 660 MS/s sampling rate for higher time resolution arbitrary waveforms. It produces sine waves with 5x lower harmonic distortion for more pure signals.
8. 34465A Keysight Digital Multimeter
This Digital Multimeter has 6 1/2 digits of resolution, and its maximum reading speed is 50,000 readings/s.
9. U1252B Keysight Handheld Digital Multimeter
This Handheld Digital Multimeter has 4 1/2 digits of resolution, and its maximum reading speed is 7 readings/s.
10. N6705C Keysight DC Power Analyzer
The 4-slot mainframe holds up to 600 W of total power, and up to 4 modules. The voltmeter accuracy is up to 0.025% + 50 uV, and up to 18 bits. The Ammeter accuracy is up to 0.025% + 8 nA, and up to 18 bits. The arbitrary waveform generator function has a bandwidth up to 100 kHz, and output power up to 500 W. The Scope function digitizes voltage and current at up to 200 kHz, 512 kpts, and up to 18 bits.
11. BK- 1550 BK Precision DC Bench Power Supply
This 108 watt bench power supply delivers 1-36V and 0-3A from its main isolated output.
12. N6781A Keysight 2-Quadrant Source/Measure Unit
This device is used for battery drain analysis. It can measure up to 20 V, ±3 A, and 20W. It has less than 30 mV of droop in response to 0.15A / us current transients.
13. N6784A Keysight 4-Quadrant General-Purpose Source/Measure Unit
This device is designed for general-purpose precision sourcing and measurement. It can measure up to ±20 V, ±3 A, and 20W. It has less than 30 mV of droop in response to 0.15A / us current transients. The output voltage can change in 10 us or at 100 kHz into a resistive load.
14. N6782A Keysight 2-Quadrant Source/Measure Unit
This device is designed specifically for advanced functional testing of a device. It can measure up to ±20 V, ±3 A, and 20W. The output voltage can change in 10 us or at 100 kHz into a resistive load.
Software:
